Magni Rotating Telehandler RTH 7.26 - 72 ft reach







The RTH 7.26 is a tough, high-performance rotating telescopic handler. It can lift loads to a height of 84 ft and is equipped with scissor stabilizers to ensure greater safety and stability during working maneuvers. The scissor stabilizers are ideal even with limited space available; even when it is only partially stabilized, the machine is programmed to provide the best possible load chart on each side. When the stabilizers are fully extended, on the other hand, they guarantee maximum machine performance over 360° as they are able to work over a very wide stabilization base. It is compatible with a huge range of accessories, thanks also to the RFID system which provides automatic recognition of the attachment and creation of the relative load charts; this telescopic handler is able to meet a wide range of applications in construction and industry. Maximum lifting capacity: 4.999 kg Maximum lifting height: 24,60 m Maximum Reach: 19,00 m Capacity at Max Height: 2.000 Kg Engine power: Deutz 100 kW - 134 hp / JCB 93 kW – 126 hp Transmission: Hydrostatic Number of speed: 2/2 Travel speed: 40 km/h Hydraulic circuit: load sensing Length: 7.620 m Width: 2.500 m Height: 3.090 m Weight: 17.230 kg Steering radius: 6,44 m Ground clearance: 329 mm Drawbar pull: 66 kN Rotation: continuous 360°
